V 0401- 130 V 0501- 50.3~166.7 V 0601- 130 V 0701- 130 V 0702- 130 V 0703-130 V 0801-33.78~126.46 V 0802-33.78~126.46
Compressor Type
V 0401- RSCR V 0501-BLDC V 0601- RSCR V 0701- RSCR V 0702- RSCR V 0703-RSCR V 0801-BLDC V 0802-BLDC
Cooling Effect
Freezer Cabinet Less than -18℃ Refrigerator Cabinet 0℃ to +5℃
General Features :
Temperature Control (Electronic/ Mechanical)
V 0401- Mechanical V 0501- Mechanical V 0601- Mechanical V 0701- Mechanical V 0702- Mechanical V 0703-Mechanical V 0801-Mechanical V 0802-Electronic
Defrosting (Automatic/ Manual)
Manual
Reversible Door
No
Handle (Recessed/ Grip)
Recessed/ Grip
Lock
Yes
Refrigerant
Capillary
Copper
Polyurethane foam blowing agent
Cyclopentene [Eco-friendly (100% CFC & HCFC Free) Green Technology]
Operating voltage
V 0401/V 0601/V 0701/V 0702/V 0703: Need Voltage stabilizer capacity is 2100VA V 0501: Wide Voltage Design (105V-276V) V 0801:Wide Voltage Design (75V-264V) N.B.: If out of voltage range(75V-264V) then suggested voltage stabilizer capacity is 2100VA.
Refrigerator Compartment :
Shelf (Material/ No.)
Wire/3
Door Basket
4
Interior Lamp
Yes
Vegetable Crisper
Yes/1
Vegetable Crisper Cover
Yes
Egg Tray
Yes/2
Can Storage Dispenser
No
Freezer Compartment :
Shelf (Material/ No.)
Wire/2
Drawer
No
Door Basket
2
Interior Lamp
No
Dimensions (Net) :
Width/mm
650
Depth/mm
650
Height/mm
1860
Packing :
Width/mm
710
Depth/mm
710
Height/mm
1910
Weight/Kg - Net/Packing
67/ 76 ± 2
Loading Capacity- 40HQ/ 40Ft/ 20Ft
66/ 48/ 24
Star rating (BDS 1850:2012)
5
Warranty Information:
Residential Use: - Replacement Guarantee: 1 Year (Condition Apply) - Main Parts (Compressor): 12 Years
- Door: 3 Years * - Spare Parts: 4 Years * - After Sales Service:5 Years *
Commercial Use: - Main Parts (Compressor): 4 Years
- Door: 1 Years * - Spare Parts: 2 Years * - After Sales Service: 2 Years *
Note:
This warranty does not cover the following cases:
1. Any damage due to accident, electrical fault, natural causes, negligence or improper installation. 2. Any damage or failure caused by unauthorized modification or alteration. 3. Products with original serial numbers that have been removed, distorted or cannot be readily recognized.
Authority keeps the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
*This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
